Tool Room & Production Machinery

All machines

FERMAT WRF 160

CNC SIEMENS 840 D. Built 2014 ca 11.000 hours. ATC 90, X= 14.800 mm. Y= 6.000 mm. Z, Ram= 1.200 mm. W, Spindle= 1.000 mm. Rotary Table 3.000 x 4.000 mm, 80 Ton.

LIEBHERR L3002 CNC Gear Hobber

LIEBHERR L3002 CNC Internal / External Gear Hobber Built 1982, Modernized 2006 CNC SIEMENS 840 D. Max Wheel diameter 3.000 mm. Max Helical Angle 45°. Internal and external Head. 44/50 kW.

FPT MAR-X 3, 2003

FPT MAR-X 3. CNC SELCA 4045 PLUS DIGITAL, Built 2003, FPT TRT25. Rotary Table, 25 Ton. Two axis Head 144 x 144.

SCHIESS RFH 30 CNC Internal Gear Hobber

SCHIESS RFH 30 CNC Internal Gear Hobber Built 1982, New CNC SIEMENS 840 D 2005. Sold as new original CNC machine 1987. Min internal gear diameter 630 mm. Max Gear diameter 3.150 mm.

FERMAT WRF 150(2G)

CNC HEIDENHEIN iTNC 530. Built 2018. Robot ATC 90, Pickup station 4 positions. Universal Micro positioning head 30 kW. Right Angle head 60 kW. X= 17.800 mm. Y= 6.000 mm. Z, Ram= 1.500 mm. W, Spindle= 1.000 mm. Rotary Table 3.000 x 4.000 mm, 80 Ton.

POMINI CNC Roll Grinder

Siemens 840D, Grinding Ø 2.200 x 11.000 mm. 80 / 180 ton. CNC Auto Calipers Diameter 870 - 2.250 mm. Eddy current crack and bruise detector probe. Ultrasound depth Probe. Built 2006.

MAZAK INTEGREX 400 III

This MAZAK INTEGREX 400-3 Lathe with CNC Mazatrol 640 MT Pro. Live milling cooling through spindle,. With CNC steadyrest and a chip conveyor. Little used.

FERMAT WRF 160

CNC HEIDENHEIN iTNC 530. Built 2013. Robot ATC 90, Pickup station 4 positions. Universal Micro positioning head 30 kW. Right Angle head 60 kW. X= 8.900 mm. Y= 7.300 mm. Z, Ram= 1.500 mm. W, Spindle= 1.000 mm. Rotary Table 3.000 x 4.000 mm, 80 Ton.

CHURCHILL TWR PLC Roll Grinder

PLC Grinding Ø 2.540 X 10.000 mm. 180 ton. Built 1990. Modernized 2004.

CHURCHILL TWB CNC Roll Grinder

Fanuc O-Mate. Grinding Ø 2.540 X 9.754 mm. 70 ton. Built 1990. Modernized 2012.

BOSTRAM 160, 2005

CNC SIEMENS 840D Powerlin. Built 2005. Pickup station for heads. Universal head. Right Angle head. X= 14.000 mm. Y= 5.000 mm. Z, Ram= 1.000 mm. W, Spindle= 1.000 mm.

Scharmann Heavycut 3.2 / TDV 5

CNC Siemens 840 C. New: 1980. Modernized with new CNC etc ca 2000. With Rotary table Scharmann TDV 5, 40 Tons, Angle head. Chipconveyor for longside X-axis. Chipconveyor for longside table travel.

MECOF CS 50 CNC Universal Milling Machine, 1997

MECOF CS 50 CNC Universal Milling Machine. CNC SELCA S3045L, Built 1997 Two axis Head 1° x 360°.

DEMMELER DRALT 2500

DEMMELER DRALT 2500. New. 2.500 x 2.500 mm, 60 ton. Linear travel 2.500 mm. Tilting 10°.

TOS WHN 130 Q, ATC 60. SIEMENS 840 D

SIEMENS 840 D. Built 2001. Table 1.600 x 1.800 mm, 12 Ton. Universal head Cooling through spindle.

MAZAK FH 6800 Horizontal Machining Center.

Horizontal Machining Center. 4 axes Mazatrol Fusion 640 M 2 Pallets 630 x 630 mm. ATC 80. 2004.

SACEM RACEM 601

CNC Siemens 840 D Solution Line. New: 1994. Modernized with new CNC etc 2018. Rotary table 2.500 x 2.500, 30 Tons, ATC 100, Angle head. DÀndrea U Tronic 5-630-S Spindle Extension. Ø 225x1200mm, 2 pcs Flooplates 4.000 x 1.500 mm

GEMENI SCNC 1000 DC x 2000 mm.

CNC lathe with GE FANUC Series O-TF. New 1990 Turning diameter 1.000 mm. Turning length 2.000 mm.

GIANA GGTRONIC 3000 TRIPLE X 1350 x 12000, New 2011.

CNC Milling, turning and internal turning Lathe SIEMENS 840 DE, Solution line, CPU 50, Windows XP, For machining complex components up to 2.600 / 3.000 mm in diameter, 12,000 mm in length and internal turning to a depth of 2.000 mm.

PAMA Speedram 4000 Horizontal Borer

PAMA Speedram 4000, Siemens 840 D sl, Built 2009. Installed new 2015 ca 10.000 spindle hours. With 100 Ton and 65 Ton Table. TW2 50 (50 KW) Two Axis Head. TS20 144 (20 KW) Angulare Head 2,5° / 144 Positions.

MAG G & L HBM MC1600 Twin Pallet CNC Horizontal Borer.

6-Axes Horizontal Borer. X=3.600, Y= 2,600, W= 2.000, Y=2.600, Z= 1.250 mm SIEMENS 840 D sl Pallet 2.500 x 1.600, 15 Ton. ATC 120. Built 2011. CE Marked.

TOS WHQ 13,8, ATC 40. SIEMENS 840 Dsl

SIEMENS 840 Dsl. Built 2013. Table 1.800 x 2.200 mm, 12 Ton. Universal head Cooling through spindle.

Scharmann Heavycut 3.3 / TDV 6

CNC SIEMENS 840 D. CNC, Electrical and mechanically overhauled by SIEMENS 2003.

DÖRRIES SCHARMANN VCE 2400/200 MC FC CNC Vertical Borer.

CNC Vertical Borer with Live Drilling and Milling spindle

KIHEUNG U 1000 Bed milling machine

KIHEUNG U 1000 Bed milling machine HEIDENHEIN iTNC 530, Built 2008 Automatic angle head 2.5° x 2,5 ° X=3,6 Y=1,25 Z=1,35 m.

TOS WHQ 13,8, HEIDENHEIN 426

HEIDENHEIN 426 Built 2000. Table 1.800 x 2.200 mm, 12 Ton. Cooling through spindle.

WALDRICH COBURG FP 250NC/7M,

WALDRICH COBURG FP 250NC/7M, CNC SIEMENS 840D SL. Hydrostatic table. 2 pst Pallets 2.500 x 7.000 mm. ISO 50/60, ATC 120. AAC 15. Built 1991, Modernized 2003.

CKD BLANSKO SKJ 50-100

CNC Single Column Vertical Borer with Live Tools. SIEMENS 840 D SL, C-axes 360.000 degrees. Table Diameter 4.770 mm. Table load 100 Ton. Max turning diameter 10.000 mm. Max working height 4.240 mm. Built 1993 modernized 2006

MAKINO MC 1513 Horizontal Machining Center.

Horizontal Machining Center. FANUC 15MA 8 Pallets 1.000 x 1.000 mm. ATC 30. 1991.

O-M Omega 70 MS

3-axis Vertical Borer and Milling Machine. Fanuc 18i-T, Built 2007. For machining complex components up to 1.350 / 1.600 mm in diameter, 1.330 mm in length ( height). Connected to FASTEMS Pallet System and TEIJO Washing Machine, with 12 pallets.

FASTEMS Automatic Pallet System.

FASTEMS Automatic Pallet System With TEIJO Washing Machine. Capacity 24 Pallets and two Set-Up Stations. With 10 Square Pallets 1.350 x 1.350 mm and 12 Round Pallets Ø 1.350. Connected to Vertical Turning and Milling O-M Omega 70 MS and 4-Axis Horizontal Machining Centre MAKINO MCD 1816.

OKUMA VTM 1200 YB

5-axis Vertical Multitasking Machine. CNC OSP-P200LA, Built 2012. For machining complex components up to 1.200 / 1.500 mm in diameter, 1.530 mm in length ( height). 6-Pallet APC Automatic Turning Setup Station. ATC 120 Capto C8.

2 FERMAT WFT 13, ATC 40. HEIDENHAIN i TNC 530.

HEIDENHAIN i TNC 530. Built 2016, Spindle hours 2.000 and 2.130. Table 1.800 x 2.200 mm, 20 Ton. Backlash free two table motors, master / slave. Automatic Micro head UHA 30 mi, and pick up station Cooling through spindle 70 bar.

FERMAT WFT 13, ATC 40. HEIDENHAIN i TNC 530.

HEIDENHAIN i TNC 530. Built 2016, Spindle hours 2.000. Table 1.800 x 2.200 mm, 20 Ton. Backlash free two table motors, master / slave. Automatic Micro head UHA 30 mi, and pick up station Cooling through spindle 70 bar.

WFL M 120 x 5000

CNC Milling, Turning and Ejector - Gun drilling Centre For machining complex components up to 1.170 / 1.360 mm in diameter, 5,000 mm in length and internal turning. ATC 72 Capto C8. 3 pcs Ejector drills magazine.

WALDRICH SIEGEN PMC 4000 AT-F17

WALDRICH SIEGEN PMC 4000 AT-F17, CNC SIEMENS 880. Hydrostatic table. ISO 50/60, ATC 400. AAC 12. Built 1994, Modernized 2003.

WALDRICH SIEGEN HFB 200

CNC SIEMENS 840 D (PL). X, 15.000 mm Y, 5.000 mm Z, Ram 1.500 mm W, Spindle 1.200 mm Tilting Head Stock up 15°, Down 30° Table Diameter 5.200 mm, 100 Ton Built 1978 Modernized 2007. Universal head Angle Head. Facing Head

POREBA TRB 135 N

CNC lathe with SIEMENS 840 D. New 2001 Hydraulic chuck 800 mm. Turning diameter 1.500 mm. Turning diameter over saddle 1.100 mm. Turning length 2.000 mm.

UNION PCR 160 Horizontal Borer

UNION PCR 160 Horizontal Borer Siemens 840 D sl, Built 2007, With UNION DV-60 Table. SEMPUCO KFU D3 Two Axis Positioning Head. SEMPUCO KF-D4/90 Angular Head 2,5° / 144 Positions.

SACEM MSC 150N

CNC Siemens 840 D. New: 1987. Modernized with new CNC etc 2007. With 2 Rotary table 2.500 x 2.500, 30 Tons, ATC 60, Angle head.

TMJ PP 362 GCNC.

TMJ PP 362 GCNC, Built 2012. Fully Automatic Electro hydraulic Band Saw. Cutting range 360, Square 430 x 460 mm.

TACCHI DB 1400 x 10000.

CNC lathe with SIEMENS 840 D. New 2015. Turning diameter 2.400 mm. Turning length 10.000 mm.

OKUMA LT 25-MY CNC Lathe.

OKUMA LT 25-MY CNC Lathe.8 Axes, With Live Tools. OSP 7000L Control, Two Chucks, Two Turrets 12 + 12 Tools. Built 1997. With FRAI Automation Portal Robot and IRCO ILS Bar feeding system.

SACEM MSC 150N

CNC Siemens 840 D. New: 1987. Modernized with new CNC etc 2007. With 2 Rotary table 2.500 x 2.500, 30 Tons, ATC 60, Angle head.

TOSHIBA BTD-13F.R22

CNC Tosnuc 888. New: 1987. With 3 Pallets 2.200 x 1.800mm, Spindle diameter 150 mm, ISO 50, ATC 180. Cooling through Spindle 30 Bar.

MITSUI SEIKI HU-63A Horizontal Machining Center.

Horizontal Machining Center. FANUC 15M 10 Pallets 630 x 630 mm. ATC 60. 1997.

Mori Seiki SL- 25 BMC 1000 CNC Lathe

Mori Seiki SL- 25 BMC 1000 CNC Lathe. With Live Tools . Fanuc 18 T Control, One Turret 12 Tools. Built 1998.

Mori Seiki ZL-45 MC CNC Lathe.

Mori Seiki ZL-45 MC CNC Lathe. With Live Tools. Fanuc 15 T Control, Two Turrets 12 + 10 Tools. Built 1998.

POREBA TCC 160 x 8.000

Turning diameter 1.600 mm. Turning over saddle 1.250 mm Turning length 8.000 mm.

Kitamyra Mycenter 5, Vertical Machining Center.

Vertical Machining Center. FANUC OMC 2 Pallets 500 x 1.200 mm. ATC 30, 1996.

Skoda SK-50A Vertical Boring Mill. Built 1972

Table diameter 4.750 mm, 45 ton. Turning diameter 5.200 mm. Turning height 3.200 mm.

FERMAT FTL V2600 CNC Vertical Borer.

Siemens Sinumerik 840 D sl. Live Drilling and Milling spindle CAT 50, 50 kW. C-axes 360.000 degrees. ATC 10. With Anglehead 0-110 degree, Anglehead 90 degree, Cooling through Spindle. New, built 2018.

CNC Horisontal Borer Ram Type TOS WPD 130

CNC HEIDENHEIN TNC 430i. With Universal Milling Head. New 1999.
